LM265SQ1-SLA1 LG Display 26.5" 1920(RGB)×1920 300 cd/m² INDUSTRIAL LCD DISPLAY

Name: LM265SQ1SLA1 LG Display 265quot 1920RGB1920 300 cdm INDUSTRIAL LCD DISPLAY
Brand: LG DISPLAY
Price: 1 USD

Quality LM265SQ1-SLA1 LG Display 26.5" 1920(RGB)×1920 300 cd/m² INDUSTRIAL LCD DISPLAY for sale

Brand Name : LG DISPLAY

Model Number : LM265SQ1-SLA1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 1000PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LM265SQ1-SLA1

TEMPERATURE RANGE : Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

RESOLUTION : 1920(RGB)×1920, 102PPI

Lamp Type : WLED

BRIGHTNESS : 300CD/M2

SIZE : 26.5 inch

BRAND : LG DISPLAY

Contact Now

LG Display LM265SQ1-SLA1 Application Details

Basic Info :	Panel Brand		Panel Model	LM265SQ1-SLA1
	Diagonal Size	26.5"	Application
	Panel Type	a-Si TFT-LCD , LCM	Model Alias	LM265SQ1 (SL)(A1)
Reliability :	Operating Temp.	0 ~ 50 °C	Storage Temp.	-20 ~ 60 °C

LG Display LM265SQ1-SLA1 Mechanical Details

Pixel Features :	Pixel Format	1920(RGB)×1920	Dot Pitch	0.0826×0.2478 mm (H×V)
Pixel Features :	Configuration	RGB Vertical Stripe	Pixel Pitch	0.2478×0.2478 mm (H×V) [102PPI]
Mechanical Size :	Display Area	475.776×475.776 mm (H×V)	Bezel Area	479.0×479.0 mm (H×V)
Mechanical Size :	Outline Dim.	491.8×491.8 mm (H×V)	Outline Depth	8.4/13.1 (Typ./Max.) mm
Outline Features :	Form Factor	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio	1:1 (H:V)	Shape Style
Holes & Brackets :	Side mounting holes
Videowall Seam :	16.0 mm (Active to Active)
Other Features :	Weight	2.21Kgs (Typ.)	Surface	Antiglare (Haze 25%), Hard coating (3H)

LG Display LM265SQ1-SLA1 Optical Details

Basic Information :	Brightness	300 cd/m² (Typ.)	Contrast Ratio	1000:1 (Typ.) (Transmissive)
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Optical Mode	IPS, Normally Black, Transmissive
	Viewing Direction	Symmetry	Response Time	14 (Typ.)(G to G) (ms)
Color Performance :	Chromaticity	Wx:0.313; Wy:0.329	Color Numbers	16.7M (8-bit)
Color Performance :	Color Temperature	6485K	White Uniformity	1.33 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	76%	sRGB	99% coverage
	Adobe RGB	77% coverage	DCI-P3	79% coverage
	Rec.2020	57% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LM265SQ1-SLA1 Backlight Details

Back-light Features:	Lamp Shape	-	Lamp Type	WLED	Life Time	30K(Min.) (Hours)
Back-light Features:	Replacement	-	Amount	-	Position	Edge light type (Left side)
Lamp Electrical :	Voltage Input	45.8±3V		Current Input	120mA (Typ.)
Lamp Electrical :	Consumption	22/23.4W (Typ./Max.)
Interface Features :	Type	Connector	Position		Lamp Driver	No
Interface Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
Interface Detail :	JST	BM06B-SHJS-TB(HF)	1.0 mm	6 pins	1 pcs	BLE-6PINS-CCAACC

LG Display LM265SQ1-SLA1 Interface Details

Signal Systerm :	LVDS (4 ch, 8-bit)			Logic Voltage	-
Signal Electrical :	Voltage Input	10V (Typ.)		Current Input	610/760mA (Typ./Max.)
Signal Electrical :	Consumption	6.1/7.6W (Typ./Max.)
Interface Features :	Type	Connector	Position	-
Connector Detail :	Brand	Model	Pin Pitch	Pins	Amount	Configuration
	LS Mtron	GT05P-51S-H38-E1500	0.5 mm	51 pins	1 pcs
	LS Mtron	GT05P-41S-H38-E1500	0.5 mm	41 pins	1 pcs

LG Display LM265SQ1-SLA1 Carton Details

Package Carton :	Amount	Net Weight	Carton Size (L×W×H)
Package Carton :	10 pcs / box	-	562×362×560 mm

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
